Industrial Solar Energy Storage System 500kW
Product Description
Remarks: 1. For different roof material, we have different mounting structure can choose.
2. All system can design as per your own request.
Specification
| 500KW Energy Storage Solar Power System Components List | |||
| Item | Model | Description | Quantity |
| Solar Panel | Mono 630W solar panel | 800 pieces | |
| PV Combiner Box | 5 Input 1 Output | 10 piece | |
| Hybrid Inverter | 500KW EU/US Standard | 1 piece | |
| 1032.192KWH Lithium Battery System (adjustable) |
51.2V100AH Lithium Battery Pack | 72 pieces | |
| High-voltage protection box | 6 piece | ||
| 7-layer 2-column battery rack | 6 piece | ||
| Mounting Support | Pitched / flat roof, ground can be Customized | 1 set | |
| PV Cable | Single-core 4mm2 PV cable | 5000meters | |
| DC Cable（Optional） | Single-core 25mm2 DC cable | 1000meters | |
| Connector | PV connector | 160 pairs | |
| Optional | Customized 10ft Container | Standard fire extinguishing sytem, Lighting, carmer, air-conditionging etc | 1set |
Product Display
Supporting OEM Service:
We provide OEM services for our hybrid solar system, including customized battery and solar panel nameplates, as well as carton and wooden box options. Contact us to learn more about our high-quality and efficient solar solutions.
We strive to provide excellent after-sales service to our customers. Our team is available to help with any issues you may have.
If there are problems with our products, simply describe the issue,upload a photo, and provide the product code.
If the issue falls within the warranty period and is not caused by human error, we'll provide solutions such as upgrading the product,replacing parts, or refunding. We are committed to ensuring your satisfaction with our products and services.
Packing & Delivery
Solar System Packing Methods
For LCL shipping, wooden box packaging is required to protect solar panels during transportation. FCL shipping allows for more standard and cost-effective packaging options. However, we can always customize the packaging if you have specific needs. Solar systems are best shipped via sea or train instead of air due to their large volume and the cost of air shipping. Battery loading is also not allowed in air shipping, which is another reason why we do not recommend it.
Project Cases
There are four different modes of operation for a solar energy system:
1) Self-Use: In this mode, the solar energy generated by the system is used to power your home or business. Any excess energy is stored in batteries for later use.
2) Time of Use: This mode is designed to take advantage of peak energy rates. The system is set up to store energy during off-peak hours and use that energy during peak hours when rates are higher.
3) Selling First: In this mode, the system is set up to sell excess energy back to the grid first before storing any energy in batteries. This is a good option if your utility company offers a good buy-back rate for excess energy.
4) Back-Up: This mode is designed to provide backup power in case of a power outage. The system is set up to automatically switch over to battery power when the grid goes down, ensuring that you have power even when the rest of the neighborhood is in the dark.
